What does cable assembly include?
Cable assemblies are collections of wires or cables banded into a
single unit with connectors on at least one end. Cable assemblies
are used to connect various types of equipment and instrumentation.
The connectors and wire configuration are very specific depending
on the application.
Electrical Characteristics:
ELECTRICAL DATA |
Impedance | 50 Ohm |
Frequency range | DC-20Ghz |
VSWR | 1.3 max |
Voltage | 60V |
Insulation Resisitance | 500 M Ohm min. |
Insertion Loss | 0.3dB max. at 1.0 GHZ/0.5DB max. at 2.0 GHZ |
MATERIAL DATA |
Bodies | Brass--gold/nickel plating |
Pin contacts | Brass--gold plating |
Socket contacts | Copper-beryllium alloy--Au plating |
Insulator | PTFE |
Cable type | 0.81mm,1.13mm,1.37mm,RG178,RG174,RG316,RG58,LMR195,LMR240,LMR400,Semi-rigid,semi-flexible,super
flexible, Formable,etc |
Application | smartphone,tablet PC,wifi antenna,GPS antenna, RF device etc |
Temperature range | -40°C to +80°C/200°C |
What Is The Purpose Of Coaxial Cable?
Coaxial cable refers to the cable with two concentric conductors,
and the conductor and shielding layer share the same axis. The most
common coaxial cable is composed of copper conductor isolated by
insulating material. On the outside of the inner insulating
material is another layer of ring conductor and insulator, and then
the whole cable is wrapped by PVC or sheath. At the same time,
coaxial cable is widely used in radio frequency or audio and video
transmission. The transmission impedance is generally 75 Ω, which
has become the standard impedance of video transmission. High
quality standard coaxial cable is generally more expensive than
twisted pair, because the reliable physical characteristics of
coaxial cable can provide excellent performance for audio and
video. The frequency and resolution of the signal and the effective
transmission distance of the cable also play a decisive role in the
audio and video system.
☀ RF cable connectors can be connected on the coaxial cable
includes: RG141/RG142/RG174/ RG178/RG179/RG180/
RG187/RG196/RG213/RG214/RG218/RG219/
RG223/RG303/RG316/RG316-DS/RG393/RG400/RG401/RG402/RG405/RG58U/1/2
/ 7/8 / LMR195/ LMR240/LMR400,ect
☀ RF cable connectors can be produced to cable assemblies with many
different cable types and custom lengths depending on your needs
and applications.
☀ If you require a special RF cable assembly configuration not
found here, you can create your own RF cable assembly configuration
by calling our sales department.
